SFZD-15
Peak power (Pmax): 15 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 0.83 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 0.92 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: USB + DC5.5*2.1
Size (Folded): 325 x 210 x 20 mm
Size (Expand): 552 x 325 x 2 mm
Size (Individual packaging): 345 x 230 x 40 mm
Weight (Net): 0.5 Kg
Weight (Gross): 0.7 Kg
Carton Size: 480 x 410 x 365 mm
Qty / carton: 20 pcs
Weight (carton): 15 Kg
SFZD-30
Peak power (Pmax): 15 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 0.83 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 0.92 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: USB + DC5.5*2.1
Size (Folded): 325 x 210 x 20 mm
Size (Expand): 552 x 325 x 2 mm
Size (Individual packaging): 345 x 230 x 40 mm
Weight (Net): 0.5 Kg
Weight (Gross): 0.7 Kg
Size (Carton): 480 x 410 x 365 mm
Qty / carton: 20 pcs
Weight (carton): 15 Kg
SFZD-38
Peak power (Pmax): 15 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 0.83 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 0.92 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: USB + DC5.5*2.1
Size (Folded): 325 x 210 x 20 mm
Size (Expand): 552 x 325 x 2 mm
Individual packaging size: 345 x 230 x 40 mm
Weight (Net): 0.5 Kg
Weight (Gross): 0.7 Kg
Size (Carton): 480 x 410 x 365 mm
Qty / carton: 20 pcs
Weight (carton): 15 Kg
SFZD- 200-30V
Peak power (Pmax): 15 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 0.83 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 0.92 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: USB + DC5.5*2.1
Size (Folded): 325 x 210 x 20 mm
Size (Expand): 552 x 325 x 2 mm
Individual packaging size: 345 x 230 x 40 mm
Weight (Net): 0.5 Kg
Weight (Gross): 0.7 Kg
Size (Carton): 480 x 410 x 365 mm
Qty / carton: 20 pcs
Weight (carton): 15 Kg
SFZD-15
Peak power (Pmax): 15 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 0.83 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 0.92 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: USB + DC5.5*2.1
Size (Folded): 325 x 210 x 20 mm
Size (expand): 552 x 325 x 2 mm
Size (Individual packaging): 345 x 230 x 40 mm
Weight (Net): 0.5 Kg
Weight (Gross): 0.7 Kg
Size (Carton): 480 x 410 x 365 mm
Qty/carton: 20 pcs
Weight (carton): 15 Kg
SFZD-20
Peak power (Pmax): 20 Wp
Working Voltage (Vmp): 6 V
Working current (Imp): 3.33 A
Open circuit voltage (Voc): 7.2 V
Short circuit current (Isc): 3.67 A
Cell:Mono 156.75
Operating temperature: –40°C until +70°C
Output: USB*2
Size (Folded): 350 x 200 x 35 mm
Size (Expand): 570 x 350 x 5 mm
Size (Individual packaging): 370 x 240 x 50 mm
Weight (Net): 0.65 Kg
Weight (Gross): 0.9 Kg
Size (Carton): 390 x 520 x 265 mm
Qty/carton: 10 pcs
Weight (carton): 10 Kg
SFZD-30
Peak power (Pmax): 30 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 1.67 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 1.83 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 350 x 285 x 35 mm
Size (Expand): 760 x 350 x 5 mm
Size (Individual packaging): 370 x 325 x 50 mm
Weight (Net): 1.45 Kg
Weight (Gross): 1.7 Kg
Size (Carton): 385 x 425 x 345 mm
Qty / carton: 8 pcs
Weight (carton): 14.6 Kg
SFZD-40
Peak power (Pmax): 40 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 2.22 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 2.44 A
Cell: Mono 156.75
Operating temperature: –40°C until+70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 405 x 350 x 35mm
Size (Expand): 890 x 405 x 5mm
Size (Individual packaging): 425 x 390 x 50 mm
Weight (Net): 1.9 Kg
Weight (Gross): 2.2 Kg
Size (Carton): 440 x 325 x 410 mm
Qty / carton:6 pcs
Weight (carton): 14.3 Kg
SFZD-60
Peak power (Pmax): 60 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 3.33 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 3.67 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 405 x 350 x 40 mm
Size (Expand): 1260 x 405 x 5 mm
ISize (ndividual packaging): 425 x 390 x 55 mm
Weight (Net): 2.55 Kg
Weight (Gross): 2.85 Kg
Size (Carton): 440 x 300 x 410 mm
Qty / carton: 5 pcs
Weight (carton): 15.4 Kg
SFZD-75
Peak power (Pmax): 90 Wp
Working Voltage (Vmp): 25 V
Working current (Imp): 3.6 A
Open circuit voltage (Voc): 30 V
Short circuit current (Isc): 3.96 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB
Size (Folded): 420 x 350 x 45 mm
Size (Expand): 1630 x 420 x 5 mm
Size (Individual packaging): 440 x 390 x 55 mm
Weight (Net): 3.3 Kg
Weight (Gross): 3.6 Kg
Size (Carton): 460 x 240 x 410 mm
Qty / carton: 4 pcs
Weight (carton): 16 Kg
SFZD-80
Peak power (Pmax): 80 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 4.44 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 4.89 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 405 x 350 x 45 mm
Size (Expand): 1630 x 405 x 5 mm
Size (Individual packaging): 425 x 390 x 55 mm
Weight (Net): 3.2 Kg
Weight (Gross): 3.5 Kg
Size (Carton): 440 x 245 x 410 mm
Qty / carton: 4 pcs
Weight (carton): 15.4 Kg
SFZD-90
Peak power (Pmax): 90 Wp
Working Voltage (Vmp): 25 V
Working current (Imp): 3.6 A
Open circuit voltage (Voc): 30 V
Short circuit current (Isc): 3.96 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB
Size (Folded): 420 x 350 x 45 mm
Size (Expand): 1630 x 420 x 5 mm
Size (Individual packaging): 440 x 390 x 55 mm
Weight (Net): 3.3 Kg
Weight (Gross): 3.6 Kg
Size (Carton): 460 x 240 x 410 mm
Qty / carton: 4 pcs
Weight (carton): 16 Kg
SFZD-100
Peak power (Pmax): 100 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 5.56 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 6.11 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 528 x 350 x 45 mm
Size (Expand): 1650 x 528 x 5 mm
Size (Individual packaging): 550 x 390 x 55 mm
Weight (Net): 4 Kg
Weight (Gross): 4.3 Kg
Size (Carton): 565 x 205 x 410 mm
Qty / carton: 3 pcs
Weight (carton): 14.3 Kg
SFZD-100C-45V
Peak power (Pmax): 100 Wp
Working Voltage (Vmp): 45 V
Working current (Imp): 2.22 A
Open circuit voltage (Voc): 54 V
Short circuit current (Isc): 2.44 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB
Size (Folded): 528 x 350 x 40 mm
Size (Expand): 1280 x 528 x 5 mm
Size (Individual packaging): 550 x 390 x 55 mm
Weight (Net): 3.2 Kg
Weight (Gross): 3.5 Kg
Size (Carton): 565 x 245 x 410 mm
Qty / carton: 4 pcs
Weight (carton): 15.4 Kg
SFZD- 100D
Peak power (Pmax): 100 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 5.56 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 6.11 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB
Size (Folded): 674 x 403 x 35 mm
Size (Expand): 1043 x 674 x 5 mm
Size (Individual packaging): 700 x 445 x 50 mm
Weight (Net): 4 Kg
Weight (Gross): 4.3 Kg
Size (Carton): 715 x 220 x 465 mm
Qty / carton: 4 pcs
Weight (carton): 18.2 Kg
SFZD-120
Peak power (Pmax): 120 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 6.67 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 7.33 A
Cell: Mono 156.75
Operating temperature:- –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 528 x 350 x 45 mm
Size (Expand): 1650 x 528 x 5 mm
Size (Individual packaging): 550 x 390 x 55 mm
Weight (Net): 4 Kg
Weight (Gross): 4.3 Kg
Size (Carton): 565 x 205 x 410 mm
Qty / carton: 3 pcs
Weight (carton): 14.3 Kg
SFZD-200
Peak power (Pmax): 80 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 4.44 A
Open circuit voltage (Voc): 21.0 V
Short circuit current (Isc): 4.89 A
Cell: Mono 156.75
Operating temperature: –40°C until +70°C
Output: DC5.5*2.1 / USB*2
Size (Folded): 405 x 350 x 45 mm
Size (Expand): 1630 x 405 x 5 mm
Size (Individual packaging): 425 x 390 x 55 mm
Weight (Net): 3.2 Kg
Weight (Gross): 3.5 Kg
Size (Carton): 440 x 245 x 410 mm
Qty / carton: 4 pcs
Weight (carton): 15.4 Kg
SFZD-300
Peak power (Pmax): 300 Wp
Working Voltage (Vmp): 18 V
Working current (Imp): 16.67 A
Open circuit voltage (Voc): 21.6 V
Short circuit current (Isc): 18.33 A
Cell: Mono 156
Operating temperature: –40°C until +70°C
Output: Cable PV1-F1*4 mm 2*2 or MC4
Size (Folded): 674 x 403 x 45 mm
Size (Expand): 2750 x 674 x 5 mm
Size (Individual packaging): 700 x 445 x 65 mm
Weight (Net): 8.4 Kg
Weight (Gross): 8.7 Kg
Size (Carton): 715 x 215 x 465 mm
Qty / carton: 3 pcs
Weight (carton): 27.6 Kg
