YCD – FL 519

YCD – FL 519

Combined Refrigerator and Freezer


Environmentally Friendly & High-efficiency
Environmentally-friendly Freon-free refrigerant and high-efficiency compressor supplied by an international famous brand ensure energy saving and high efficiency.


Refrigeration System

  • Two compressors and separate control of the upper refrigeration chamber and the lower freezing chamber.
  • High-precision Computerized Temperature Control
  • The digital temperature display can indicate operating status clearly, and users may set the high temperature / low temperature alarm points based on their needs.


Thermal Insulation System
The CFC-free polyurethane foam technology and the thicker insulating layer can improve the effect of thermal insulation.


Temperature Control System:

  • High-precision microcomputer temperature control system with built-in control / alarm sensors for high / low temperature, ambient temperature and evaporator temperature etc. ensuring the safe and stable running
  • 1-inch high brightness digital temperature display with 0,1ºC display precision, the temperature can be set freely


Refrigeration System:

  • Equipped with high-efficiency compressor and international brand fan, ensuring energy saving and silent running
  • Two compressors and separate control of the upper refrigeration chamber and the lower freezing chamber


Security System:

  • Perfect audible and visual alarm system makes it safe for storage. Equipped with alarm functions including high / low temperature alarm, high ambient temperature alarm, sensor failure alarm, door ajar alarm, power failure alarm, etc.
  • Buzzer alarm for the door opening more than 1 minute, alarm automatically muted when the door is closed


Human-oriented:

  • The freezing chamber interior is equipped with 6 drawers, refrigerating chamber 3 coated steel wired shelf for object storage;
  • 4 casters for the front and back, 2 front casters with lock.
  • Specially equipped with external door handle and padlock to prevent unauthorized opening


Scope of Application:
Suitable for use in scientific research, cryogenic test on special materials, blood plasma cryopreservation, low temperature resistance test on biological materials, vaccines, biological products and military products, etc. Suitable for use in research institutions, the electronic industry, the chemical industry, hospitals, the health & disease prevention system, laboratories in colleges & universities, military enterprises, etc.



  • Cabinet Type: Upright
  • Capacity (L): 519, R:323, F: 196
  • Internal Size (W x D x H): R: 750 x 610 x 740 mm, F: 650 x 560 x 565 mm
  • External Size (W x D x H): 910 x 740 x 1972 mm
  • Package Size (W x D x H): 990 x 855 x 2140 mm
  • Weight (N): 186 kg
  • Weight (G): 215 kg


Performance:

  • Temperature Range: R: 2 ~ 8ºC, F: -10 ~ -40ºC
  • Ambient Temperature: 16 ~ 32ºC
  • Cooling Performance: R: 5, F: -40ºC
  • Climate Class: N
  • Controller: Microprocessor
  • Display: Digital display



Refrigeration:

  • Compressor: 2 pc
  • Cooling Method: R: Forced air cooling, F: Direct cooling
  • Defrost Mode: R: Automatic, F: Manual
  • Refrigerant: R: R 600 a, F: R 290
  • Insulation Thickness (mm): R: 50 F: 100



Construction:

  • External Material: Spray cold rolled steel plate
  • Inner Material: Stainless steel
  • Shelves: R: 3 + 1 (stainless steel), F: 6 (ABS)
  • Door Lock with key: Yes
  • Lighting: LED
  • Access Port: 2 pcs. Ø 25 mm
  • Casters: 4 (2 casters with brake)
  • Data Logging: USB
  • Interval: Record every 10 minutes
  • Recording Time: 2 years
  • Door with Heater: Yes
  • Backup Battery: Yes



Alarm:

  • Temperature: High / Low temperature, High ambient temperature
  • Electrical: Power failure, low battery
  • System: Sensor failure, Door ajar, Built-in USB datalogger failure, Communication failure



Electrical:

  • Power Supply: 220-240 V, 50 Hz
  • Rated Power: 398 W
  • Power Consumption: 5,17 kWh / 24 h
  • Rated Current: 3,57 A



Accessories:

  • Standard: RS 485, remote alarm contact
  • Options: Printer
