HS15V-D

15 kW


Heating A+7 / W 35°C:

  • Heating capacity norm: 15,23 kW
  • Power consumption: 3,53 kW
  • COP: 4,31



Heating A+7 / W 55°C:

  • Heating capacity norm: 14,31 kW
  • Power consumption: 4,58 kW
  • COP: 3,12



Heating A+2 / W 35°C:

  • Heating capacity norm: 12,35 kW
  • Power consumption: 3,31 kW
  • COP: 3,73



Heating A­–10 / W 55°C:

  • Heating capacity norm: 10,23 kW
  • Power consumption: 4,61 kW
  • COP: 2,22


ErP Heating:

  • Seasonal energy efficiency (W 35°C / W 55°C): 192,7 / 150,8 %
  • Energy efficiency rating (W 35°C / W 55°C): 4,89 / 3,85 SCOP
  • Seasonal energy efficiency (W 35°C / W 55°C): A+++ / A+++



Refrigerant:

  • Type: R290
  • GWP: 3
  • Filing capacity: 1,15 kg
  • CO2 equivalent: 0,0035 ton



Features:

  • Outdoor sound power full load (heat): dB(A)
  • Outdoor dimension (H*W*D): mm
  • Outdoor N / W: kg
  • Operation range (Outdoor ambient): –25 ~ 46 °C
  • Water outlet (heat): 20 ~ 70 °C
  • Water outlet (cool): 5 ~ 20°C
  • Compressor type: TWIN ROTARY
  • Heat exchanger: Brazes Plate Heat Exchanger
  • Defrost method: Process reversal
  • Power control: Inverter control
  • Pipe connection Inlet / Outlet: External thread
  • Pipe diameter: 33,25 mm
  • Supply voltage: 3 ~
  • Frequency: 50 Hz
  • Voltage: 400 V
  • Voltage range Min. / Max.: -10 / +10 %
  • Working current (Max.) heating: 11,5 A
  • Recommended fuses: 15 A
  • Recommended cable size: 5 x 2,5 mm²
